ZigBee Smart Plug (US/Switch/E-Meter) SWP404

Main Feature:

The Smart plug WSP404 allows you to switch your devices on and off and allows you to measure power and record total used power in kilowatt hours (kWh) wirelessly via your mobile App.


  • Model: 404
  • Item Dimension: 130 (L) x 55(W) x 33(H) mm
  • Fob Port: Zhangzhou, China
  • Payment Terms: L/C,T/T




  • Product Detail

    Tech Specs

    video

    Product Tags

    Main Features:

    • Complies with ZigBee HA1.2 profile to work with any standard ZHA ZigBee Hub
    • Converts your home appliances to smart devices, such as lamps, space heaters, fans, window A/Cs,decorations,and more, up to 1800W per plug
    • Controls your home devices on/off globally via the Mobile APP
    • Automates your home by setting schedules to control connected devices
    • Measures the instantaneous and accumulative energy consumption of the connected devices
    • Switches on/off the Smart Plug manually using the toggle button on the front panel
    • Slim design fits with standard wall outlet and leaves the second outlet free
    • Supports two devices per plug by providing two outlets one at each side
    • Extends the range and strengthens ZigBee network communication

    Products

    404.16 zt

    40424

    404

    Application:

    yyt



    Video:



    Package :

    shipping


  • Previous:
  • Next:

  • ▶ Main Specification:

    Wireless Connectivity

    ZigBee 2.4GHz IEEE 802.15.4

    RF Characteristics

    Operating frequency: 2.4GHz
    Internal PCB Antenna
    Range outdoor/indoor: 100m/30m

    ZigBee Profile

    Home Automation Profile

    Operating Voltage

    AC 100 ~ 240V

    Max. Load Current

    125VAC 15A Resistive; 10A 125VAC Tungsten; 1/2HP.

    Calibrated Metering Accuracy

    Better than 2% 2W~1500W

    Dimension

    130 (L) x 55(W) x 33(H) mm

    Weight

    120g

    Certification

    CUL, FCC

  •
