ZigBee Motion Sensor with wireless alarm for smart home multisensor PIR313

Main Feature:


  • Model: 313
  • Item Dimension: 83(L) x 83(W) x 28(H) mm
  • Fob Port: Zhangzhou, China
  • Payment Terms: L/C,T/T




  • Product Detail

    Tech Specs

    video

    FAQ

    Product Tags

    Main Features:

    • ZigBee HA 1.2 Compliant
    • PIR motion detection
    • Temperature, humidity measuring
    • Illuminance measurement
    • Vibration detection
    • Long battery life
    • Low battery alerts
    • Anti-tamper
    • Sleek design

    ▶ Product:

    313 313-1 313-2 313-3

    Application:

    app1

    app2

     ▶ Video:

    Shipping:

    shipping


  • Previous:
  • Next:

  • ▶ Main Specification:

    Operating Voltage
     DC 3V (2*AA battery)
    Rated Current
     Standby Current: ≤40uA
    Alarm Current: ≤30mA
    Illuminance (Photocell)
    Range: 0 ~128 klx
     Resolution: 0.1 lx
    Temperature
    Range:-10~85°C
    Accuracy:±0.4
    Humidity
    Range: 0~80% RH
     Accuracy: ±4%RH
    Detecting
     Distance: 6m
     Angle: 120°
    Battery Life
    All-in-one version: 1 years
    Networking
     Mode: ZigBee Ad-Hoc Networking
     Distance: ≤ 100 m (open area)
    Operating Ambient
    Temperature: -10 ~ 50°C
     Humidity: maximum 95%RH (no
    congelation)
    Anti-RF Interference
    10MHz – 1GHz 20 V/m
    Dimension
    83(L) x 83(W) x 28(H) mm
