Smart Thermostat with Humidity Control and WiFi | PCT533

Main Feature:

The OWON PCT533 is a 24VAC smart thermostat with humidity control, built-in occupancy sensing, and a 4.3-inch color touchscreen. It supports WiFi control, compatible humidifiers and dehumidifiers, 4H/2C heat pumps, dual fuel, and wireless room sensors for residential and light commercial HVAC systems.


  • Model: PCT533/PCT533C
  • Dimension: 143 (L) × 82 (W)× 21 (H) mm
  • Weight: 350g
  • Certification: FCC, RoHS




  • Product Detail

    MAIN SPEC

    Video

    Product Tags

    Main Features

    • Humidity Sensing & Control – Built-in humidity sensing with support for compatible humidifiers and dehumidifiers through dedicated accessory terminals.
    • Occupancy Sensing – Built-in occupancy detection for smarter HVAC control.
    • 24VAC HVAC & Heat Pump Compatibility – Supports up to 2H/2C conventional and 4H/2C heat pump configurations, including dual fuel, auxiliary heat, and emergency heat.
    • Wireless Remote Room Sensors – Extend temperature and humidity monitoring across multiple rooms.
    • 4.3" Color Touchscreen – Intuitive interface for smart HVAC control.
    • Smart Scheduling & Energy Tracking – 7-day scheduling, preheating/precooling, and HVAC energy usage reports.
    • Smart Connectivity – WiFi, BLE pairing, Tuya Smart app, OTA updates, API integration options, and voice assistant support.

    Humidity & Occupancy-Based HVAC Control

    The OWON PCT533 is a smart thermostat with humidity control designed for compatible North American 24VAC HVAC systems. It combines built-in temperature, humidity, and occupancy sensing with advanced heating and cooling control.

    • Humidity Sensing & Control

    The PCT533 monitors indoor humidity and supports compatible humidifiers and dehumidifiers through dedicated ACC1 and ACC2 accessory terminals, helping maintain comfortable indoor conditions.

    • Occupancy-Based Smart HVAC Control

    Built-in occupancy detection and programmable schedules support more responsive HVAC operation. Compatible wireless room sensors extend temperature and humidity monitoring across multiple rooms for flexible comfort management.

    Product

    24vac heating and cooling system,  4.3 in. full-colorl LCD touchscreen, 7-day customizable Fan/Temp programming schedule
    24vac heating and cooling system, smart HVAC control, 4.3 in. full-colorl LCD touchscreen, 7-day customizable Fan/Temp programming schedule
    24vac heating and cooling system,  4.3 in. full-colorl LCD touchscreen, 7-day customizable Fan/Temp programming schedule, smart HVAC control
    24vac heating and cooling system, 4.3 in. full-colorl LCD touchscreen, 7-day customizable Fan/Temp programming schedule, smart HVAC control
    24vac heating and cooling system, 4.3 in. full-colorl LCD touchscreen,  7-day customizable Fan/Temp programming schedule, smart HVAC control

    Application

    The OWON PCT533 smart HVAC thermostat is designed for:
    • Residential HVAC Systems – Smart homes and advanced heating and cooling applications.
    • Multifamily Housing – Apartments and residential property management projects.
    • Light Commercial Buildings – Offices and small commercial HVAC applications.
    • Smart Building Integration – Connected HVAC control and energy management systems.
    • HVAC OEM/ODM Projects – Customized thermostat solutions for HVAC brands and system integrators.

    HVAC Wiring Diagrams & Installation

    Explore the wiring configurations supported by the OWON PCT533 WiFi Thermostat.

    Conventional HVAC - Standard heating and cooling

    Heat Pump - Auxiliary & Emergency Heat

    PCT533 24VAC dual fuel thermostat wiring diagram for 2-stage heat pump and secondary heating

    Dual Fuel - Heat pump + secondary heating

    Humidity Accessories - Humidifier & Dehumidifier

    FAQ

    Q1: Does the PCT533 support occupancy-based HVAC control?
    A: Yes. PCT533 features built-in occupancy sensing to support smarter comfort management and occupancy-aware HVAC control strategies.

    Q2: Can the PCT533 control humidifiers and dehumidifiers?
    A: Yes. PCT533 supports compatible 1-wire or 2-wire humidifiers and dehumidifiers through dedicated accessory terminals, with built-in humidity sensing.

    Q3: Is the PCT533 compatible with heat pump and dual fuel systems?
    A: Yes. PCT533 supports 24VAC HVAC systems, including up to 4H/2C heat pump configurations, 2H/2C conventional systems, and dual fuel/hybrid heating.

    Q4: Can the PCT533 be customized for HVAC brands and system integrators?
    A: Yes. OWON offers OEM/ODM customization options for HVAC brands, distributors, and system integrators. Customers can discuss product branding, firmware requirements, connectivity, and project-specific integration options with OWON.

    Q5: Does the PCT533 support wireless remote room sensors?
    A: Yes. Wireless remote room sensors extend temperature and humidity monitoring beyond the thermostat location, helping improve multi-room comfort and address hot and cold spots.



    Wi-Fi
    • 802.11 b/g/n @ 2.4GHz
    BLE
    • For Wi-Fi Pairing
    Display
    • 4.3 in. full-colorl LCD touchscreen
    • 480*800 pixel display
    Sensors
    • Occupancy
    • Temperature
    • Humidity
    Power
    • 24 VAC, 50/60 Hz
    Temperature range
    • Desired Temperature: 40° to 90°F (4.5° to 32°C)
    • Sensitivity: +/− 1°F (+/− 0.5°C)
    • Operating: 14° to 122°F (-10° to 50°C)
    Humidity range
    • Sensitivity: +/− 5%
    • Operating: 5% to 95% RH (non-condensing)
    Dimensions
    • Thermostat: 143 (L) × 82 (W)× 21 (H) mm
    • Trim plate: 170 (L) × 110 (W)× 6 (H) mm
    TF card slot
    • For firmware updates and log collection
    • Format requirement: FAT32
    Mounting Type
    • Wall Mounting
    Accessories
    • Trim plate
    • C-wire Adapter (Optional)
